Art.-Nr.1023335
EAN 8435392860208
Mondraker Crafty R
Farbe: Blue/Black
Größe: XL
Empfohlene Körpergröße: 185 - 195cm

Voraussichtl. Liefertermin: 06.04.2023
   Voraussichtl. Liefertermin: 06.04.2023


statt 6.799,00 EUR (UVP) pro Stück (inkl. MwSt. zzgl. Versandkosten)

6.459,05 EUR

Sie sparen 5% (339,95 EUR)
Menge:

Produktdetails

- Rahmen: Crafty 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers.
- Dämpfer: Fox Float-X LV Performance, 205x65mm. Settings: compression 2 positions lever, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings
- Gabel: Fox 38 29 Float FIT GRIP EVOL Performance, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload
- Vorbau: Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore
- Lenker: Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
- Griffe: Onoff Desert, 1lock-on, 135mm
- Sattelstürze: Onoff Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm
- Sattel: FIZIK Terra Aidon X5 145mm
- Bremse vorne: Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
- Bremse hinten: Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
- Felgen: Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes
- Speichen: Mavic J-bend double butted, contactless lacing
- Reifen vorne: Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
- Reifen hinten: Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
- Kurbelgarnitur: Race Face Aeffect ebike, 165mm
- Kette: Sram SX Eagle, 12s, Powerlock
- Schalthebel: Sram Trigger NX Eagle, 12s, X-Actuation 1:1, single click
- Kassette: Sram PG-1210, 11-50T, 12s
- Motor: Bosch Performance Line CX Cruise (25Km/h) Smart System
- Batterie: Bosch Powertube 750Wh
- Display: Bosch Kiox 300 / Bosch Mini Remote / Bosch System Controller
