Produktdetails

- Rahmen: F-Play 24 6061 Alloy Stealth evo, hydroformed tubing, Zero Suspension System, 120mm travel, one piece bolt-on upper link, integrated internal non-removable battery, Tapered head tube, HHG internal cable routing, BSA bottom bracket, QR 9mm rear axle, 1x drivetrain compatible
- Dämpfer: X-Fusion 02PRO R, 210x47.5mm. Settings: low-speed rebound, air preload. 45x8mm top and bottom bushings
- Gabel: X-Fusion Velvet RL 26, 100mm, air spring, tapered steerer tube, 9x100mm axle, 32mm aluminum stanchions, 41mm offset. Settings: lockout, rebound, air preload
- Vorbau: Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore
- Lenker: MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9º backsweep, 5º upsweep, 31.8mm barbore
- Griffe: Onoff Twin, 1lock-on
- Sattelstürze: MDK XC 0-R, 6061 T6 Alloy, diameter 31.6mm, length 300mm
- Sattel: SDG Fly JR
- Bremse vorne: Sram Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
- Bremse hinten: Sram Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
- Felgen: MDK-XP1 24 TLR, 25mm internal width, tubeless ready, 32 spokes
- Speichen: CN round stainless steel
- Reifen vorne: Kenda Booster 24x2.4 single compound 30TPI, wire bead
- Reifen hinten: Kenda Booster 24x2.4 single compound 30TPI, wire bead
- Kurbelgarnitur: Samox DM 30T steel, 152mm
- Kette: Sram PC1031 10s, Powerlock
- Schalthebel: Sram trigger GX 10s, X-actuation 1:1
- Kassette: Sram PG 1020 11-36T, 10s
- Motor: Mahle-Ebikemotion X-35
- Batterie: Mahle-Ebikemotion Internal 250Wh
- Display: Mahle-Ebikemotion
